In this blog post, we will see how the applications running in the EKS pods can connect to the S3 bucket using the IAM role for the service account (IRSA).
The applications running in EKS pods can use AWS SDK/AWS CLI to make a call to the S3 bucket. In order to connect successfully, we need to distribute the AWS credentials to the containers. If we have multiple applications running, we have to distribute the credentials to all the containers. In order to have control of the distribution, AWS recommends creating the IAM role for the service account, which will help in providing the least privileged access to a particular container. With IRSA, the pod which is associated with the service account will get permission to talk to the other AWS services.
EKS pods are the Kubernetes resources, whereas S3 is an AWS resource. So, to have a good handshake between the two, we need an IRSA to be created.
Running Elastic Kubernetes cluster (EKS)
kubectl
AWS account
Permission to create the IAM role and Policies
AWS CLI
eksctl
For the EKS cluster created, by default there will be an OIDC issuer URL associated with it. To use the IAM role for the service account, the OIDC provider needs to exist with OIDC issuer URL. To create the OIDC provider, we will use eksctl command line utility.
>> eksctl utils associate-iam-oidc-provider --cluster demo-cluster --approve
The demo-cluster is the name of the EKS cluster.
To verify if an OIDC provider is created, we need to run the following command.
>> aws iam list-open-id-connect-providers
We will get the below details if the OIDC provider was successfully created.
{
"OpenIDConnectProviderList": [
{
"Arn": "arn:aws:iam::17483678901:oidc-provider/oidc.eks.ap-south-1.amazonaws.com/id/D510BCG4F7E27AM04AZNS95G6914V4A0"
}
]
}
Create the file s3-policy.json with the below contents.
{
"Version": "2012-10-17",
"Statement": [
{
"Effect": "Allow",
"Action": "s3:GetObject",
"Resource": "arn:aws:s3:::demo-bucket"
}
]
}
We will create an IAM policy to allow access to get the object from the S3 bucket named demo-bucket using the below command.
aws iam create-policy --policy-name s3-policy --policy-document file://s3-policy.json
Create a file demo-service-account.yaml. We have to create a Kubernetes service account with the name demo-sa in the namespace demo-s3 using the below yaml file.
apiVersion: v1
kind: ServiceAccount
metadata:
name: demo-sa
namespace: demo-s3
Now apply the below command to create a service account.
kubectl apply -f demo-service-account.yaml
Create a file demo-role-relationship.yaml for the trust policy.
{
"Version": "2012-10-17",
"Statement": [
{
"Effect": "Allow",
"Principal": {
"Federated": "arn:aws:iam::17483678901:oidc-provider/oidc.eks.ap-south-1.amazonaws.com/id/D510BCG4F7E27AM04AZNS95G6914V4A0"
},
"Action": "sts:AssumeRoleWithWebIdentity",
"Condition": {
"StringEquals": {
"oidc.eks.ap-south-1.amazonaws.com/id/D510BCG4F7E27AM04AZNS95G6914V4A0:aud": "sts.amazonaws.com",
"oidc.eks.ap-south-1.amazonaws.com/id/D510BCG4F7E27AM04AZNS95G6914V4A0:sub": "system:serviceaccount:demo-s3:demo-sa"
}
}
}
]
}
Once it is done, we need to create the IAM role and attach the trust policy.
aws iam create-role --role-name s3-role --assume-role-policy-document file://demo-role-relationship.json"
Now, we will attach the IAM policy to the role created above.
aws iam attach-role-policy --role-name s3-role --policy-arn=arn:aws:iam::17483678901:policy/s3-policy
The service account needs to be annotated to the IAM role using the below command.
kubectl annotate serviceaccount -n demo-s3 demo-sa eks.amazonaws.com/role-arn=arn:aws:iam::17483678901:role/s3-role
Create a file s3-demo-deployment.yaml . Notice that, we are using the 'default' service account that does not have access to the S3 bucket as we have only configured access to the 'demo-sa' service account.
apiVersion: apps/v1
kind: Deployment
metadata:
name: nginx
namespace: demo-s3
spec:
selector:
matchLabels:
app: nginx
template:
metadata:
labels:
app: nginx
spec:
serviceAccountName: default
initContainers:
- name: demo-aws-cli
image: amazon/aws-cli
command: ['aws', 's3', 'cp', 's3://demo-bucket/test.txt, '-'
containers:
- name: my-app
image: nginx
Now, let us run the deployment file using kubectl apply -f s3-demo-deployment.yaml.
kubectl get pods -n demo-s3
NAME READY STATUS
nginx-8665cf9655-7h5fs 0/1 Init:CrashLoopBackoff
Observe above that, the pod did not come up successfully as the Init container was not able to access the s3 bucker demo-bucket. We can also check this using the below command.
kubectl logs -l app=nginx -c demo-aws-cli -n demo-s3
download failed: s3://demo-bucket/test.txt to - An error occurred (403) when calling the HeadObject operation: Forbidden
Now, let us change the service account to demo-sa in the init container as shown below.
spec:
serviceAccountName: demo-sa
initContainers:
- name: demo-aws-cli
image: amazon/aws-cli
command: ['aws', 's3', 'cp', 's3://demo-bucket/test.txt, '-'
Now reapply using the command kubectl apply -f s3-demo-deployment.yaml.
NAME READY STATUS RESTARTS AGE
nginx-12455f5f955-9g8gs 1/1 Running 0 1d
Let us verify if it was able to connect to S3 and print the contents in the console.
kubectl logs -f nginx-12455f5f955-9g8gs -n demo-s3
Hi!!!! Testing IAM role for a service account.
As we have used the demo-sa service account, it was able to successfully connect to S3 bucket.
In this blog, we have seen what is IRSA and how to use it to access the S3 bucket from the EKS pods. We have also seen, how the pod is connected to a particular service account and how it uses IRSA to connect to the S3 bucket.
